A 2014 Harley Sportster starter won't turn engine over means that the starter motor is not able to rotate the engine in order to start it. This can be caused by a number of different issues. One possibility is that the starter motor itself is faulty and needs to be replaced. Another possibility is that there is a problem with the starter relay, which is responsible for providing power to the starter motor. Additionally, the issue could be with the battery, as it may not have enough charge to power the starter motor. It could also be that the starter motor is not properly aligned with the engine, preventing it from turning it over. Lastly, there may be an issue with the electrical system, such as a loose connection or a blown fuse, which could be preventing the starter motor from functioning properly. Overall, it is important to diagnose and address the root cause of the starter won't turn engine over issue in order to get the Harley Sportster running properly again.
If you're having trouble getting your 2014 Harley Sportster to start, there could be a few different issues at play. Here are some common problems that might cause your starter to fail to turn the engine over:
- Engine run switch in OFF position: The engine run switch is a safety feature that allows you to turn off the engine while the motorcycle is in motion. Make sure it's in the ON position before trying to start the bike.
- Ignition Switch not in IGNITION position: The ignition switch controls the power to the motorcycle's electrical systems. Make sure it's in the IGNITION position before trying to start the bike.
- Discharged battery or loose/corroded connections: A weak battery or loose or corroded connections can prevent the starter from turning the engine over. Check the battery charge and tighten or clean the connections as needed.
- Starter control circuit, relay, or solenoid faulty: The starter control circuit, relay, and solenoid work together to control the starter motor. If any of these components are faulty, the starter may not function properly.
- Security system activated: Some Harley Sportsters are equipped with a security system that can prevent the motorcycle from starting if it's not disarmed. Make sure the security system is deactivated before trying to start the bike.
- Motorcycle in gear and clutch not pulled in: If the motorcycle is in gear and the clutch is not pulled in, the engine will not turn over. Make sure the bike is in neutral and the clutch is fully disengaged before trying to start it.
- Main fuse not in place: The main fuse protects the electrical system from damage. If it's not in place, the starter will not function. Make sure the main fuse is properly installed.
- Jiffy stand down and transmission in gear: If the jiffy stand is down and the transmission is in gear, the starter will not function. Make sure the jiffy stand is up and the transmission is in neutral before trying to start the bike.
In summary, there are several potential causes of a 2014 Harley Sportster starter that won't turn the engine over. By troubleshooting and addressing these issues, you should be able to get your bike running smoothly again.
The diagnosis and troubleshooting information provided in this article is based on the 2014 Harley 883/1200 factory service manual.
